Reliability Test
Reliability engineering runs through the normal life span of the electronic equipments—from the phase of product design, manufacture, install, use, and to maintain. Reliability based design and manufacture are vital to ensure the product to be reliable over its life cycle.
During the electronic equipments’ use, they may encounter the following environmental conditions--high temperature, low temperature, high humidity, low pressure, hazardous gas, fungi, salt spray, shock, vibration, radiation, electromagnetic interference, etc. When subject to these stresses, a product with reliability-based design (anti-severe environment, thermal and EMC designs), fabrication technology, management, and analysis techniques, is able to operate appropriately. Failure analysis model building is one of the most important considerations to assure the product’s reliability under prescriptive environment conditions.
| Reliability test item form | |||||
|---|---|---|---|---|---|
| № | Test Item | Equipment Parameter | Test Production Object | Test Parameter | |
| Climatologically test | |||||
| 1 | High-temperature test | Room temperature～100℃ | Complete appliance、metal material parts、 plastic material parts、electric parts | test temperature、test time、samples dimension、samples number、operating or not、test standard | |
| 100℃～ 300℃ | |||||
| 2 | Low-temperature test | 0℃～-40℃ | Complete appliance、metal material parts、 plastic material parts、electric parts | test temperature、test time、samples dimension、samples number、operating or not、test standard | |
| -40℃～70℃ | |||||
| 3 | High-low temperature cycle test |
temperature：-40℃～150℃ humidity：20%～98% |
Complete appliance、metal material parts、 plastic material parts、electric parts | test time、cycles 、test temperature &time samples dimension、samples number、operating or not、test standard | |
| ４ | Constant temperature and humidity test |
temperature：-40℃～150℃ humidity：20%～98% |
Complete appliance、metal material parts、 plastic material parts、electric parts | test temperature and humidity、test time、samples dimension、samples number、operating or not 、test standard | |
| ５ | Thermal shock test | temperature: -65℃～150℃ | Complete appliance、metal material parts、 plastic material parts、electric parts | Test time、Cycle period、High temperature & time、Low temperature & time、Samples dimension、Samples number、Operating or not、test standard | |
| ６ | Speedy temperature test |
Temperature:-70℃～150℃ Charge rate:20℃/min |
Complete appliance、metal material parts、 plastic material parts、electric parts | test temperature、test time、samples dimension、samples number、operating or not、test standard | |
| ７ | Temperature/humidity/vibration synthetically test | 1m3 Temperature & humidity chamber，1t vibration estrade | Complete appliance、metal material parts、 plastic material parts、electric parts | test temperature and humidity、test time、Vibration frequency，vibration period、samples dimension、Samples weight、samples number、operating or not、test standard | |
| ８ | Salt spray test | NSS,ASS,CASS |
Metal parts （include paint and zincification material ） |
test temperature、test time、samples dimension、samples number、test standard | |
| Alternation charge salt spray | |||||
| 9 |
IP degree IP Code |
IP XY X=dustproof Y= waterproof |
X: 1-4 | Complete appliance | IP degree、samples number、test standard |
| X: 5-6 | |||||
| Y | |||||
| 10 | UV Lamp Test | UVA340/UVB313 |
Plastic material, Rubber material |
test time、sample material、samples number、operating or not、test standard | |
| 11 | Xenon Lamp Test | － |
Plastic material, Rubber material |
test time、sample material、samples number、operating or not、test standard | |
| 12 | UL94 Burning degree test | V-0,V-1,V-2,HB |
Plastic material, Rubber material and Other |
Test class、Samples number、Color difference、Sample material | |
| 13 | Gas Corrupt Test | SO2/ H2S/ NO2/Cl2/NH3 | metal material, Plastic material, | test time、Gas category、sample material、samples number、test standard | |
| 14 | Low air pressure test | Air press and temperature adjuster | Complete appliance | samples dimension、samples number、operating or not、test standard | |
| 15 | HALT/HASS | Typhoon 4.0 | semi-finished products（electricity product） | test time、acceleration、samples number、test standard | |
| Mechanical test | |||||
| 16 | Vibration Test |
horizontal，vertical vibration sine、random、sine & random 2-2000Hz |
Complete appliance, metal parts, electricity parts |
Vibration frequency，vibration period、vibration axe （X、Y、Z axes）、acceleration、samples dimension、samples number、samples weight、operating or not、test standard | |
| 17 | Mechanical Shock Test | 30000m/s2（3000g） |
Complete appliance, metal parts, electricity parts |
Vibration frequency，vibration period、vibration axe （X、Y、Z axes）、acceleration、samples dimension、samples number、samples weight、operating or not、test standard | |
| 18 | Bump Test | 250kg, 50m/s2～300 m/s2 |
Complete appliance, metal parts, electricity parts |
librate time of every side 、face of swing（face of Ｘ、Ｙ、Ｚaxes）、samples number、 | |
| 19 | Simulate Transportation | Class III road:35km/h load 1500kg | Packing product | Travel distance、samples dimension、samples number、samples weight、test standard | |
| 20 | Packing Drop Test |
Max.loading:0～100Kg Sample max. dimension: 1000*800*1000(mm)； Drop high 300-1500mm； Max. load 0-100kg |
Packing product | samples dimension、samples number、drop high、drop times、drop place 、samples weight、test standard | |
| 21 | Heap Test | Max. load:5t | Packing product | samples dimension、samples number、samples weight、test standard | |
| 22 | Resist Press Test | Max. load:5t | Packing product | samples dimension、samples number、samples weight、test standard | |
| 23 | Pull/Pressure/Flex Test | － |
Metal material、 Plastic material、PCB |
pull（press、bend）point、Pull（press、bend）degree、report（chinese、english） | |
| 24 | Rub Test | alcohol，pencil，rubber | Silk-screen product（parts） | Friction time、friction material | |
| PCB test | |||||
| 25 | Cross section test | Lead-free solder PCB | PCB |
position of slice、direction of incision、face of slice、 microscope magnification |
|
| 26 | Tin whisker check | Lead-free solder PCB | PCB | Magnification of microscope | |
| 27 | Solder pull test | Lead-free solder PCB | PCB | Position of welding spot | |
| 28 | Solder ability test | － | PCB | ||
| 29 | Air Pressure Cooker Test | － | Pressure cooker，pressure pot | pressure range、intensity of pressure | |
| 30 | Coating thickness Test | clad layer thickness > 1um | metal clad and plating on plastics product |
ply、position of measure |
|
